Product Details:
✅ Compliance standard: IEC 60947-4-1 / GB 14048.4
✅ Rated frequency: 50 / 60 Hz
✅ Rated operational voltage (Ue): up to 690 V AC
✅ Current setting range: 0.1 A – 630 A (varies by model)
✅ Tripping class: Class 10A
✅ Protection function: Overload protection
✅ Phase loss and phase imbalance detection
✅ Locked rotor protection
✅ Structure: Three-phase bimetallic element with adjustable current dial
✅ Reset mode: Manual / automatic selectable
✅ Temperature compensation: Ensures precise operation under different ambient temperatures
✅ Trip indicator: Mechanical flag for visual trip status
✅ Test and stop button: For on-site operation check and circuit stop function
✅ Auxiliary contact: 1 NO + 1 NC, electrically isolated
✅ Mounting type: Plug-in mounting with CHINT contactor or independent base mounting
✅ Mechanical life: ≥ 1,000,000 operations
✅ Electrical life: ≥ 100,000 operations
✅ Ambient temperature: −5 °C to +40 °C
✅ Storage temperature: −25 °C to +70 °C
✅ Altitude: ≤ 2000 m
✅ Relative humidity: ≤ 95% RH (non-condensing)
✅ Pollution degree: Class 3
✅ Protection degree: IP20 (enclosed)
✅ Vibration resistance: ≤ 5.9 m/s²
✅ Accessories: Mounting base (MB1–MB4), interconnection kit and extension wiring module
✅ Compatible CHINT contactors: NC1, NC6, NC8, and NC2 series

Warranty:
1 year official brand warranty.
